Aohong High temperature graphite gland packing pure PTFE gland packing with oil

Application: For use in pumps, valves, reciprocating and rotating shafts, mixers and agitators. Especially designed for services involving surface speeds and temperature higher than those normally specified for pure PTFE packings. Can be safely used in all chemical pump applications with the exception of molten alkali metals, fluoride, fuming nitric acid and other strong oxidizing agents. It is also against water, steam, petroleum derivatives, vegetable oil and solvents.
PTFE graphite gland packing
Size: 6*6mm to 50*50mmPacking: 5Kg or 10Kg per roll customized weight is available.
Usage :Used as sealing material on rotary shafts, reciprocating pistons and valve spindles. The working medium are steam. air
industrial water, petroleum, etc.
Pure PTFE packing with oil
Size: From 6 x 6 mm to 50 x 50mm.
Packaging: In coils of 5 to 10 kg, other weight on request; as precut length.Application: Designed for valves and lower shaft speed applications under medial pressure in food processing, pharmaceuticals,
paper mills, fiber plants where high purity and corrosion resistance is required.
G-PTFE & ARAMID IN ZEBRA BRAIDED PACKING
Size: From 6 x 6 mm to 50 x 50mm.
Packing: In coils of 5 to 10 kg, other weight on request; as precut length.Application: Offers the strength of aramid fibers, the thermal dissipating and low friction property of graphited PTFE. Used in
reciprocating pumps, mixers, reactors and valves for petrochemical, paper and sugar industries , power stations.
Details Images
Pressure
Roating
15 bar
Reciprocating
100 bar
Static
200 bar
Shaft speed
12m/s
Density
1.65/cm3
Temperature
-150~+280°C
PH range
0~14
Hot Sale Products
Aohong pure PTFE gland packing
Aohong Graphite and PTFE gland packing
Aohong pure graphite gland packing
Packing and Delivery
1)5 Kg or 10Kg per rolls then 20Kg in a carton box /plastic woven bag
2)delivery time:15-20days after the order confimed
3)supply ability:500meter per day
