Aohong Liner Guide Turcite Sheets by wholesale price made in china

Slideway turcite is a kind of composite material of PTFE with the nano polymer as the base,

In view of high-end guide soft belt products for all kinds high precision of machine tools, CNC equipment and processing centers.

It contains rich particles of solid lubricants, excellent friction and wear properties.
Special properties
• High wear resistance;
• Low friction;
• Good shock absorption;
• Good lubrication;
• Easy maintenance.
Material
PTFE+bronze
Colour
Blue
red
green
Density (g/cm3)
3.4
3.3
3.3
Coefficient of linear expansion (40-120°C)
7.7
7.62
7.5
Tensile strength (Mpa)
17
16
14
Elongation (%)
180
170
150
Compressive strength (Mpa)
33--42
30--40
28---38
Bending strength (Mpa)
25-30
25-30
23--29
Non-notched impact strength (KJ/m2)
>16
>15
>14
Wear(PV=0.7N/mm2.m/s)
0.010-0.020
0.010-0.020
0.010-0.020
Friction loss performance

(dry friction) Friction coefficient (μ)
0.13--0.20
0.15-0.21
0.16-0.23
Detailed Images
Packing&Shipping
Packed in cartons
Company Introduction
Hengshui Aohong Technology Co., Ltd. is an industrial company with an integration of industrial production and trade.
Our company specializes in producing sealings gasket sheets,thermal insulation cloths, rope, tape, level gauge glasses (plane,reflex), turcite  sheet etc.
All of our products sell well in both domestic and international markets.
FAQ
Q: Are you factory, or only a trading company?
A: Factory, and our factory is located in Wangtong town, Jing county, Hengshui, Hebei
Q:Could I get some samples, and how?
A: No problem, we provide free samples, and it is only needed for you to pay for the shipping charge, your courier account is also ok(such as DHL).
Q: Can you give me some discount?
A: Usually the discount depends on the quantity. However we can discuss it.
Q: What's the payment terms?
A: Our normal practice: 30% deposit of total amount before production, and 70% balance payment before shippment. However this is open for discussion.
